BMW Wheel Fitment

We've documented eight BMW platforms so far: the G87 M2, G80 M3, G82/G83 M4, G20 M340i and G30 M550i, plus the F80 M3, F82/F83 M4 and E90/E92/E93 M3. Every G-chassis car uses a 5×112 bolt pattern, a 66.6mm center bore and M14×1.25 lug bolts with a 60° conical seat, torqued to 103 lb-ft. The F8x and E9x M cars use 5×120 with a 72.6mm bore, so wheels don't swap between generations. The G80, G82 and G87 all run ET20 at 9.5″ front / 10.5″ rear from the factory, which is why they share so many aftermarket setups. Carbon ceramic brakes need at least a 19″ wheel. The F80 and F82 run 9″/10″ at ET29/ET40, and the E9x M3 uses M12×1.5 bolts at ET29 front / ET23 rear. The M340i and M550i sit at much higher offsets (ET25–27/ET40 and ET30/ET44). Each guide covers factory specs, documented aftermarket setups and brake clearance. For other BMW models, request a guide.
